Industrial Shot Blasting Machine
industrial shot blaster
shot peening machine manufacturers
The YG industrial shot blasting machine, also known as an industrial shot blasting cleaning machine or automatic shot blasting machine, is an industrial device that uses high-speed projectiles to impact the surface of workpieces, achieving rust removal, oxide scale removal, deburring, and surface strengthening. Its core function is to improve the cleanliness and roughness of workpiece surfaces, laying the foundation for subsequent painting, welding, and other processes. It is widely used in the surface pretreatment and strengthening of various metal workpieces and is an indispensable key piece of equipment in industrial production. Traditional manual rust removal and small polishing equipment are not only inefficient and produce uneven cleanliness, but also suffer from high labour costs and environmental non-compliance. The YG industrial shot blasting machine, as a professional device integrating intelligent control and high-efficiency shot blasting technology, has become the preferred choice for industrial surface treatment due to its core advantages of precise rust removal, multi-condition adaptability, and environmental protection and energy saving. It can be flexibly combined with steel shot blasting machines, hanger-type shot blasting machines, and other specialised equipment according to the workpiece type, perfectly adapting to the needs of mass production and handling irregularly shaped workpieces. If your project also requires an industrial shot blasting machine, please get in touch with us now.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
5 Key Features of the YG Industrial Shot Blasting Machine
Intelligent and Precise Speed Control, Controllable Cleaning Level: Equipped with a PLC intelligent control system, it can precisely adjust the shot blasting speed, abrasive flow rate, and conveying speed. The workpiece surface cleanliness can reach Sa2.5-Sa3.0 levels, with uniform and controllable roughness, meeting the surface quality requirements of different processes.
Abrasive Recycling and Reuse, Energy Saving and Consumption Reduction: Equipped with a fully automatic abrasive sorting and recycling system, the abrasive recovery rate is over 98%, reducing abrasive consumption; at the same time, it uses energy-saving motors, reducing energy consumption by 20% compared to traditional equipment, significantly saving operating costs in the long term.
Multi-Scenario Adaptability, Wide Range of Applications: Compatible with various workpiece types such as steel plates, profiles, castings, and parts. It can switch to roller conveyor shot blasting machine mode to adapt to batch processing of plates, or use the hanger type shot blasting machine for processing irregularly shaped and large workpieces, eliminating the need for separate equipment purchases.
Environmentally Compliant, Worry-Free Operation: The pulse dust removal system efficiently filters dust, with a purification rate of 99.5%, preventing dust leakage; it is also equipped with an abrasive collection device to avoid workshop pollution, fully complying with industrial environmental protection requirements and avoiding environmental penalties.
Comprehensive Safety Protection, Stable Operation: The equipment is equipped with a closed protective casing, an emergency stop button, overload protection, leakage protection, and other multiple safety devices to guarantee the safety of operators fully; the high-wear-resistant component design reduces the failure rate, enabling 24-hour continuous operation, ensuring stable and reliable performance.
YG Industrial Shot Blasting Machine Working Principle: A Simple and Easy-to-Understand Intelligent Shot Blasting Logic
The core working principle of the YG Industrial Shot Blasting Machine is to propel abrasive media onto the workpiece surface using a high-speed rotating impeller. The impact force of the abrasive media removes impurities and strengthens the surface. The entire process can be divided into four key steps, which are simple and easy to understand:
Step 1: Workpiece Conveying and Positioning. Depending on the workpiece type, the appropriate conveying method is selected. Flat workpieces are conveyed via a roller conveyor shot blasting machine, while irregularly shaped workpieces are conveyed via a hanger-type shot blasting machine. The workpieces are smoothly fed into the enclosed shot blasting chamber, and the equipment automatically positions the workpiece.
Step 2: Abrasive Media Acceleration and Projection. After starting the equipment, the motor drives the shot blasting impeller to rotate at high speed. The abrasive media enters the impeller from the media hopper and is accelerated to high speed by centrifugal force. It is then uniformly projected onto the workpiece surface at a preset angle, impacting and removing scale, rust, burrs, and other impurities.
Step 3: Abrasive Media Recycling and Dust Treatment. After impact, the abrasive media falls to the bottom of the chamber. A sorting device screens out qualified abrasive media, which is then returned to the media hopper for recycling. Impurities are collected and processed. Simultaneously, the dust collection system operates, absorbing the dust generated during the process, and the purified air is discharged after meeting standards.
Step 4: Workpiece Output and Inspection. After processing, the conveying system sends the workpiece out of the shot blasting chamber. Operators can inspect the cleanliness of the workpiece surface. If secondary processing is required, parameters can be adjusted through the control system, and the workpiece can be sent back into the chamber for processing, achieving automated continuous production.
Case Studies of American and German Customers Using YG Industrial-Grade Shot Blasting Machines
Case 1: Thomas, Head of a German Steel Structure Company.
Customer Background: Responsible for the processing of large bridge and factory steel structures, with extremely high requirements for workpiece surface treatment accuracy and environmental protection. Previous equipment had problems with excessive dust and uneven treatment.
Key Problems Solved: Dust removal efficiency reached 99.5%, fully complying with EU environmental standards; intelligent speed control ensures consistency in batch workpiece processing, with stable cleanliness reaching Sa2.5; processing efficiency increased by 50%, significantly shortening the production cycle.
Customer Testimonial: “The YG industrial shot blasting machine perfectly combines efficiency and environmental protection. Its stable performance ensures the quality of steel structure processing, and the after-sales service is professional and timely. It has become an indispensable piece of equipment in our production line.”
Case 2: Lisa, Project Manager of an American Automotive Parts Company.
Customer Background: Produces automotive chassis and engine components, requiring batch processing of component surfaces, demanding both efficient cleaning and surface strengthening.
Key Problems Solved: Significant surface strengthening effect, increasing component wear resistance by 25%; automated operation reduces labour costs by 60%; suitable for mass production, with strong continuous operation capability without malfunctions.
Customer Testimonial: “The performance of YG’s equipment exceeds our expectations. The Industrial Shot Blasting Machine not only improves production efficiency but also enhances product quality. It helps us save costs and gain more market competitiveness. We will continue to cooperate with YG for subsequent equipment upgrades.”
What Are the Core Differences Between Shot Blasting Machines and Sandblasting Machines? How Do You Choose the Right Equipment for Your Project?
I. Different Core Working Principles
YG Industrial Shot Blasting Machine: Uses centrifugal force to drive a high-speed rotating impeller, which accelerates and propels abrasive media (steel shot, cast iron shot, etc.) onto the workpiece surface. The impact force of the abrasive media achieves rust removal, descaling, and other effects, operating in an “active projection” mode.
Sandblasting Machine: Uses compressed air to drive a high-pressure airflow, which propels abrasive media (quartz sand, corundum, etc.) onto the workpiece surface. Cleaning is achieved through the impact force of the airflow, operating in a “airflow projection” mode.
II. Different Media and Characteristics
Shot Blasting Machine: Uses metal abrasive media (such as steel shot, cast iron shot), which are highly durable and reusable (recycling rate above 98%). It combines cleaning and surface-strengthening functions, suitable for slight shaping of the workpiece surface.
Sandblasting Machine: Primarily uses non-metallic abrasive media (quartz sand, corundum, etc.), which are mostly single-use. A wide range of abrasive particle sizes is available, providing stronger cleaning power, but without surface strengthening effects.
III. Differences in Applicable Scenarios and Effects
Shot Blasting Machine: Suitable for batch processing of industrial workpieces (such as steel structures, automotive parts), offering high efficiency and a large processing area. It allows for automated continuous operation, achieving uniform cleanliness (Sa2.5-Sa3.0 grade), and simultaneously increasing the surface hardness of the workpiece, preparing it for painting and welding processes. For example, the YG industrial shot blasting machine, when combined with a roller conveyor shot blasting machine, can efficiently process large quantities of sheet metal.
Sandblasting Machine: Suitable for small batches, irregularly shaped workpieces, or high-precision cleaning requirements (such as moulds, precision parts). It can specifically treat corners, crevices, and other hard-to-reach areas, but its efficiency is lower, and dust pollution is relatively more severe, requiring enhanced dust removal measures.
IV. Different Energy Consumption and Environmental Costs
Shot Blasting Machine: Abrasive media are reusable, resulting in low long-term operating costs. Combined with a pulse dust removal system (purification rate ≥99.5%), it offers strong environmental compliance and is suitable for large-scale production.
Sandblasting Machine: Abrasive media are single-use, resulting in high consumable costs. High-pressure airflow consumes significant energy, and dust emissions are higher than those of shot blasting machines, leading to higher environmental treatment costs.
Summary and Selection Recommendations
When to choose a shot blasting machine? If your workpieces are large steel structures, castings, or mass-produced metal parts, and you prioritise high efficiency, low cost, and environmental friendliness, then an industrial shot blasting machine is definitely the best choice.
When to choose a sandblasting machine? If your workpieces have extremely complex shapes (such as the internal cavities of precision moulds), are thin or fragile (prone to deformation from high-intensity impact), or you only need to perform occasional small-area rust removal, a sandblasting machine will be more flexible.
