YG excavator screening bucket is your ideal choice for efficient handling and sorting of bulk materials. This versatile attachment transforms your excavator into a mobile screening device, greatly simplifying on-site work processes. Whether screening soil, sand and gravel, construction waste, or compost, YG’s excavator screening bucket can complete the task with outstanding efficiency. Its rugged design and efficient screening drum or screen inside can quickly separate materials of different particle sizes to ensure that you get the finished product you need. This screen bucket is easy to install and intuitive to operate, without the need for additional complex equipment or a large number of personnel. It can help you reduce the number of material transportation times, reduce waste disposal costs, and increase the reuse value of materials. When you need a reliable and efficient rock screening bucket to handle various types of mining or construction waste, choose the YG excavator screening bucket.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
Excavator Screening Bucket Parameter
| Model Number | Applicable Tonnage of Excavator(T) | Operating Flow(L/min) | Working Pressure(Mpa) | Self Weight(Kg) | Number of Revolutions Per Minute(RPM) |
| YG01 | 1.5-3 | 20 | 10-12 | 158 | 35 |
| YG02 | 3.5-5.5 | 30 | 10-12 | 245 | 60 |
| YG08 | 6-10 | 45 | 12-15 | 530 | 65 |
| YG012 | 11-18 | 65 | 15-18 | 1020 | 65 |
| YG016 | 19-28 | 80 | 18-22 | 1920 | 65 |
| YG018 | 29-38 | 150 | 18-22 | 2430 | 65 |
Advantages of YG Excavator Screening Bucket
- Significantly improve production efficiency: Integrating screening operations into the excavator eliminates the trouble of multiple material transfers and the use of independent screening equipment, greatly shortening operation time and improving the overall project progress.
- Significantly reduce operating costs: Reduce the need for dedicated screening equipment, loaders, and additional operators, thereby saving equipment rental, fuel consumption, and labor costs. It is more focused on screening than an excavator rock crusher bucket, and can handle specific materials more economically.
- Optimize resource utilization: It can effectively separate recyclable materials (such as recycled aggregates and high-quality soil), reduce the amount of waste treatment, realize the recycling of resources, and improve the environmental benefits of the project.
- Increase the added value of materials: By screening and grading materials, finished products of different particle sizes can be obtained to increase the commercial value of materials, such as screening construction waste into backfill aggregates or high-quality garden soil.
- Strong operational flexibility: On-site screening operations can be carried out at any construction site with an excavator, without the need for a large site and complex installation, which is particularly suitable for projects with limited sites or dispersed operations.
Application of YG the Excavator Screening Bucket
- Construction and demolition waste treatment: Screening of mixed waste such as concrete, bricks, and soil after demolition to separate recyclable aggregates and inert earthwork.
- Landscaping and soil remediation: Screening of soil, peat, compost, and vegetation to produce high-quality garden soil or soil improvement before site leveling.
- Gravel field and mining operations: Preliminary screening of mined sand and gravel to separate aggregates of different particle sizes in preparation for subsequent processing. For projects that require stone processing, especially when you need an efficient rock screening bucket, YG’s products can significantly improve your material handling capabilities.
- Municipal engineering and pipeline laying: Screening of backfill soil to ensure the uniformity and quality of backfill materials and avoid damage to pipelines.
Working Principle of YG Rotary Screening Bucket
When the excavator boom drives the screening bucket into the material pile and scoops it up, the hydraulic motor in the screening bucket starts to drive the internal screening drum to rotate (or activate the vibrating screen). The material tumbles inside the drum or screen as it rotates or vibrates. Fine particles smaller than the size of the screen hole (such as fine sand and fine soil) will fall through the screen hole to the bottom of the screen bucket, while coarse materials larger than the size of the screen hole (such as stones and large pieces of waste) will remain inside the screen bucket. When the screening process is completed, the operator only needs to flip the screen bucket to dump the coarse material at the designated location. The whole process realizes continuous and automatic screening of materials, greatly saving time and manpower.
YG Excavator Screening Bucket Price and Purchase Information
In addition to the efficient excavator screening bucket, YG also provides a variety of other high-quality excavator accessories to meet your diverse engineering needs. These accessories complement the screening bucket and can further enhance the functionality and operating efficiency of your excavator, allowing your equipment to truly achieve multi-purpose use:
- Excavator Rock Saw: When facing hard rocks, concrete walls, or complex geology that requires precise cutting, the YG excavator rock saw is an ideal choice. It is suitable for occasions that require delicate operations such as urban transformation, tunnel excavation, and mine cutting.
- Hydraulic Compactor: After completing earth backfilling or foundation leveling, the YG hydraulic compactor can provide a strong vertical impact force to effectively compact the loose soil, sand, or gravel, which is essential for projects such as road construction, pipeline laying, and site leveling.
- Multi-Purpose Grapple: The YG multi-purpose grab has a flexible jaw design that can grab materials of various shapes and sizes, from large rocks and wood to various types of waste. It not only has a strong gripping force, but it can also perform simple sorting and loading operations. It is a powerful assistant for site cleaning, material handling, and waste disposal. It can be used in conjunction with a screening bucket to further improve the refinement of material handling.
As a manufacturer, YG is committed to providing you with highly competitive factory-direct prices to ensure that you get high-quality products at the best price and enjoy perfect after-sales service. Contact us now to get a quote.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
