If you work in industrial cleaning, cold chain logistics, or food preservation, you undoubtedly know how crucial dry ice (solid carbon dioxide) is as a consumable. It provides efficient cleaning and low-temperature preservation, but long-term reliance on external suppliers often presents several headaches: high costs, as you have to cover the supplier’s production, transportation, and profit margins; inconsistent quality, with varying dry ice densities affecting cleaning effectiveness; and, most importantly, sublimation losses, where even short-distance transports cause dry ice to “disappear.” Every dry ice shortage directly impacts your production schedule and cleaning quality.
Is there a permanent solution to these problems? The answer is to own your own YG dry ice pelletizer. This device is like a magical “dry ice factory,” efficiently converting liquid carbon dioxide from storage tanks into high-density, standard-sized dry ice pellets. Having it means you no longer have to pay for other logistics and intermediaries, significantly reducing your dry ice costs. Whether you’re supplying consistent 3mm particles to your dry ice blasting machine or producing large quantities of dry ice pellets for sale in refrigerated shipping, this dry ice pellet machine has the flexibility to handle the demand. Contact us today for more information.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
Dry Ice Pelletizer Parameter
| Model | YG60 | YG120 | YG200 |
| Dry Ice Specifications | ϕ3-ϕ19 | ϕ3-ϕ19 | ϕ3-ϕ19 |
| Dry ice density | 1.3-1.45 | 1.3-1.45 | 1.3-1.45 |
| Output per hour | 60kg | 120kg | 200kg |
| Motor power | 2.2KW | 3.7KW | 7.5KW |
| Work stress | 20KN | 20KN | 20KN |
| System pressure | 25Mpa | 25Mpa | 25Mpa |
| Working pressure | 20Mpa | 20Mpa | 20Mpa |
| Oil pumps | 60L/min | 100L/min | 150L/min |
| Dimensions (L)*(W)*(H) | 700*640*1150(mm) | 1000*740*1450(mm) | 1420*1000*1750(mm) |
Working Principle of the Dry Ice Pelletizer
The dry ice pelletizer utilizes mechanical high pressure and temperature differentials to convert liquid carbon dioxide into solid pellets:
- Decompression and Expansion (Snowflake Formation): Liquid CO2 from a high-pressure storage tank is introduced into a low-pressure extrusion chamber. Here, the liquid CO2 rapidly decompresses, undergoing “adiabatic expansion.” A portion of the liquid vaporizes, absorbing a significant amount of heat, causing the remaining CO2 to rapidly solidify into white, solid “dry ice snowflakes” at -78.5°C.
- Extrusion: A hydraulic system drives a massive extrusion piston, forcing the loose dry ice snowflakes in the chamber under tremendous pressure into a pre-assembled porous mold.
- High-Density Pellet Production: Under intense pressure, the dry ice snowflakes are compressed into uniform, high-density solid cylinders. As the piston continues to move, these dry ice cylinders are pushed out of the mold and cut into pellets of standard length at the outlet.
- Collection: The resulting dry ice pellets for sale can be directly collected and stored in an insulated container for future use.
YG Dry Ice Pelletizer Features and Specifications
- High Conversion Efficiency: The optimized gas-to-liquid conversion ratio elevates the liquid CO2 to dry ice conversion rate to industry-leading levels, effectively reducing raw material costs.
- One-Touch Start and Fully Automatic: The machine is easy to operate; connect the liquid CO2 tank and press the start button to achieve continuous, fully automatic production.
- Multiple Pellet Sizes: The mold can be quickly changed, enabling the production of 3mm high-density pellets (suitable for fine dry ice cleaning machines) and 16mm large pellets (ideal for cold chain transportation).
- Consistent High Density: Unique hydraulic extrusion technology ensures uniform and high-density dry ice pellets, which are crucial for effective cleaning in dry ice blasting machines.
- Remote Diagnosis and Safety Monitoring: Equipped with a remote control and fault diagnosis system, the machine monitors the safe operating status of high-voltage components in real time and supports automatic shutdown protection.
Case Studies and User Reviews of YG’s Dry Ice Pelletizers from Customers in the United States and Canada
Case 1: Dry Ice Cleaning Service Provider in the U.S. Midwest
- Customer Background: A large industrial cleaning service company in the U.S. Midwest, whose operations primarily rely on dry ice blasting machines.
- Problem Solved: Long-term dependence on external suppliers for dry ice purchases resulted in high costs and significant sublimation losses during transportation.
- Product Used: YG dry ice pelletizer ($200 kg/h medium-sized machine).
- Results: After implementing in-house dry ice production, the client immediately reduced dry ice consumable costs by 40%. The fresh, high-density dry ice produced significantly enhanced dry ice cleaning machine efficiency and customer satisfaction.
- Customer Testimonial: “Purchasing YG’s dry ice pelletizer was the best investment we’ve ever made. It not only drastically lowered our operating costs but also ensured our dry ice blasting machines consistently use the highest quality dry ice.”
Case 2: Australian Biopharmaceutical Cold Chain Logistics Company
- Customer Background: An Australian cold chain company specializing in biopharmaceutical and vaccine transportation required a stable supply of high-density 16 mm pellets.
- Challenge Addressed: Needed a reliable, high-volume supply of 16 mm dry ice pellets to maintain ultra-low temperatures during long-distance transport.
- Product Used: YG Dry Ice Pellet Machine (with interchangeable molds).
- Results: The YG dry ice pellet machine’s high-density output and $16 mm$ die configuration perfectly met cold chain requirements. The client can now produce required dry ice quantities on demand, eliminating sublimation risks during the “last mile.”
- Client Feedback: “We are delighted to produce our own dry ice pellets for sale. YG’s equipment is highly reliable, producing dense dry ice that ensures the safety of our pharmaceutical shipments.”
Price & Purchase Information
The price of a YG dry ice pelletizer is primarily influenced by factors such as production capacity (e.g., 100 kg/h or 500 kg/h), degree of automation, hydraulic system brand, and whether an automated packaging system is included.
Price Influencing Factors:
- Production Capacity: The higher the production capacity, the larger the machine and the more powerful the hydraulic system, and the higher the price.
- Mold Quantity and Specifications: Models that can be configured with multiple mold sizes are more expensive.
- Hydraulic System Configuration: Models that use hydraulic components from leading international brands are more reliable and more expensive.
- Automation Integration: Models with automatic weighing, packaging, and remote monitoring functions are more expensive.
Purchasing Channels and Contact Information:
YG offers factory-direct dry ice pellet machine solutions, ensuring you receive the best prices and professional after-sales service. For detailed dry ice pellet production solutions or a customized quote, please contact us by email, phone, or WhatsApp.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
Dry Ice Pellets Machine Price – YG Machinery Manufacturer
From cold chain preservation in the food industry to industrial equipment cleaning and pharmaceutical transportation in the medical industry, the YG dry ice pelletizer is finding use in a growing number of applications. In scorching Malaysia, logistics companies use it to cool tropical fruit in containers, ensuring fresh
ness across thousands of miles to Europe. In the frigid northern United States, hospitals rely on it to produce dry ice to maintain a low temperature for vaccine transportation, ensuring its effectiveness. In factory-intensive Australia, auto repair shops and electronics factories use it in conjunction with dry ice cleaning machines to clean engines and precision parts, removing oil stains while minimizing damage. As demand for dry ice continues to grow, the YG dry ice pelletizer will adapt to these new scenarios, from newly opened small bakeries to expanding cold chain logistics companies and even research institutions requiring low-temperature labs. By leveraging its flexible dry ice production capabilities, the YG dry ice pelletizer will provide stable and efficient dry ice solutions for a wider range of industries, making it an indispensable and practical device in various fields. Contact us now for more information and the latest quote.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
